Home / Products / Double Glass Module - Color / Double Glass PV Solar Panels Module Yellow Color

Double Glass PV Solar Panels Module Yellow Color Custom

PVB Double Glass PV Module, Select Fuying New Materkals!
Double Glass PV Solar Panels Module Yellow Color

Double Glass PV Solar Panels Module Yellow Color

Half-cell battery technology, brand new circuit design.

Super frame, can bear 5400Pa mechanical load test.

Drainage system design to prevent deformation and cracking of the frame due to freezing.

Significantly reduce the risk of hot spots and reduce power loss.

Excellent anti-PID performance and strict quality control ensure the high reliability of the product.


  • parameter
  • description
Small version of color PVB double glass module
9BB-166 Standard test conditions:AM1.5,E=1000W/m2,TC=25℃
Pmax 175W-370W Maximum system voltage 1500V
Tolerance range 0~5W Maximum system current 15-16A
Vpm 34.0V Operating temperature -40~85℃
Ipm 10.89A Cell type Monocrystalline silicon
Voc 41.2V Weight (Kg) 22kg
Isc 11.41A Specification (mm) 1785*1046*5.3
Large panel color PVB double glass module
9BB-166 Standard test conditions:AM1.5,E=1000W/m2,TC=25℃
Pmax 210W~450W Maximum system voltage 1500V
Tolerance range 0~5W Maximum system current 15-16A
Vpm 41.2V Operating temperature -40~85℃
Ipm 10.7A Cell type Monocrystalline silicon
Voc 49.3V Weight (Kg) 25.2kg
Isc 11.2A Specification (mm) 2089*1033*5.3

Jiaxing Fuying Composite Materials Co., Ltd.

Jiaxing Fuying Composite Materials Co., Ltd. is one of the professional China Double Glass PV Solar Panels Module Yellow Color suppliers, a wholly-owned subsidiary of ZHEJIANG DECENT NEW MATERIAL CO.,LTD. with a registered capital of 200 million yuan. The company is located in Tongxiang, the permanent site of the World Internet and the bridgehead of Zhejiang to Shanghai.

As a famous ODM Double Glass PV Solar Panels Module Yellow Color company, the company is committed to building a composite functional film, custom Double Glass PV Solar Panels Module Yellow Color, PVB double glass photovoltaic module application demonstration and promotion base, and a PVB research institute, forming a marketing center, industry conference center, product display, and a PVB composite functional film and photovoltaic product manufacturing base. Promote the application of PVB multi-functional membrane to the field of photovoltaics, and promote the products to the world.
